Sovol SV08 Belt Helper for X Carriage

Model details

Platform
Printables
Price
Free
License
see the platform page
The author sets the terms — check them on the model page before printing for sale.
Formats
STPSTL
  • 213 Likes
  • 1 147 Downloads
  • 10 Makes
  • 20 Comments
  • 5 426 Views

Author:Nadir @ CN3D

Published

Download on Printables

Description

I have added a big version to accommodate for V4 and for Xenomorph with Eddy

You need to orient the part in the slicer

this is a simple idea not only to keep the belts in place and aligned but you can also stretch them to fit your new build like Xenomorph, Spartacus, Shroud V4 or any other toolhead that you want to install in your 3D printer. can be used in any Voron stile gantry 3D printer.

Print settings 4 walls 35% gyroid infill 5 top and bottom

BOM 8x M3x4,5 OD 4mm or longer heat set insert 4x M3x8 4x M3x25 or 30

Enjoy!
