Tekton 1/2 in. Drive Impact Socket Insert For Milwaukee Packout Organizer

Inserts for the Packout organizer designed for ½ in. Drive SAE and Metric Tekton deep impact sockets, size ranging from 8 - 38mm and 5/16 - 1-½ in. as well as the universal joint, 3 in. extension and 10 in. extension.

These inserts were designed to be printed to fit the Bambu X1C, so I had to split the model to be able to fit the parts, they are joined together with some dowels. Each tray will need 4 of the “Pins .95” and 2 of the “Pins .45” to join them together. You may need to scale these pins up or down to get the right fit depending on your printer calibration.

The middle tray can be printed as 1 piece, you just need to rotate it to 45 degrees in the slicer. I added an undercut on the bottom of it because I got a little warping when I printed it flat, the undercut helps it sit on the bottom better.

Printed in PETG

PRINT SETTINGS

-tree supports on

-top z distance 0.2mm

-3 walls

-5 bottom layers

-5 top layers

-8% infill gyroid

Here are links to all of the socket kits and attachments this was designed for, although different brand sockets may fit as well. Designed to fit 3" long sockets

https://www.tekton.com/1-2-inch-drive-deep-6-point-impact-socket-set-sid92335

https://www.tekton.com/1-2-inch-drive-deep-6-point-impact-socket-set-sid92306

https://www.tekton.com/1-2-inch-drive-x-3-inch-impact-extension-sia21103

https://www.tekton.com/1-2-inch-drive-x-10-inch-impact-extension-sia21110

https://www.tekton.com/1-2-inch-drive-impact-universal-joint-sia22102
