Description

Thank you for supporting me!

This is another free 3D model made available for you. I love sharing my models, but designing, testing, polishing, uploading and maintaining them is a lot of work. In case you enjoy this model, please leave a small Donation or Buy me a Coffee . Thank you!

Design

Spool adapter for spools with an inner diameter between 46 and 52mm. Tested for many spools from 250 grams to 2 kg.

Printing Instructions

Both PLA and PETG filaments are fine. Printed using a 0.4mm nozzle and 0.2 layer height. 20 or 25% infill. I recommend to place the Inner item with the nut hole down and turn support from build plate on.

Other parts required

- 3 x M10 nuts - 1 x M10 threaded rod 16cm or longer - 1 x 20mm washer with a 10.x mm hole
