Bosch 18V Tool Holder - With names and Thicker for Belt Hooked Tools

Model details

Platform
Printables
Price
Free
License
CC-BY-NC-SA
Non-commercial use only, with credit; share remixes under the same license.
Formats
STL
  • 2 Likes
  • 48 Downloads
  • 0 Makes
  • 0 Comments
  • 318 Views

Author:VaughnR

Published

Description

Tool holders for Bosh Professional 18V tools (particularly those with pistol-style handles) to hang under a bench or shelf. These prints have a simple colour change at the appropriate layer: I printed both .20mm and .24mm layers without problems, with text on top (obviously).

The thick version is sufficient to hold a drill (or whatever tool) with the standard belt hook attached. The thin version is a little thicker than the original to allow space for the labels. Unlabeled versions are included, you can add whatever label you like using Tinkered (a 1mm exposed text is sufficient).

Printed at 0.24mm in ABS with three walls and 20% gyroid infill on BambuLabs X1C in Sport mode for the ones shown here. I used 40mm 8 gauge screws to fit the thick version; 20 mm screws were sufficient for the thin ones. I am contemplating a French cleat version for some other tools (multitool, plane and jigsaw) to go on the tool wall behind my bench - not sure about the cantilevered weight that might develop.
