Neptune 3 / 4 Series Cable Chain

update(mar 01, 2025): 4Pro has been made compatible by Woodworker - see remixes

update(jan 24, 2025): 4pro is currently incompatible with the section ZMount<>Extruder cause it a very different mounting plate - just follow the recommended path!

This chain system is trying to overcome some shortcommings of the original Chain system for the Neptune 4 Series. There are Adapter-chainlinks available so you can mix and match the old and new system if you like.

Features

- tighter tollerances - less sag - strainrelief for the x Axis stepper and Limit switch cable - N4 Plus/Max compatible - mulitple Options regarding Z-Mount to Extruder Assembly chaining - STEP File available - seperate PDF file containing some tips on how to use the various Parts of this system - large internal volume chain links and - outside cable tie mounts(TBD) - Adapter from and to the old system to allow use of anything that was original build for the old system Printing Recommendations

- Material: PETg or ASA/ABS - Slicer Orca, Wall Generator Arachne - Linewidth/layerheight: 0.4/0.2 - 3 Wall, 5 toplayer, 3 Bottom layer - For weightsaving 2 / 4 / 3 is ok(10% weight saving across the system) - 6-10% Infill Honeycomb or Gyroid - Arachne “min wall width” 75% - Wallorder: inner/outer/inner - Support required for Z-Mount, Sidesupport. normal supports, from buildplate only - Chainlink Count - N4/Pro: 21 bottom, 5 Sidesupport<>ZMount, 18 to extruder - N4 Max: 35 bottom, 5 Sidesupport<>ZMount, 30 to extruder - try to avoid Brim use for chainlinks - may require significant cleanup - assembly requires glue!! Versions

v12b - minor link optimisations v12 - rebuild adapter links, compatibility to SilencedFrost X-Linear Rail Mod v11b - added Neptune 3 Extruder Mount to have it fully N3 series compatible v11 - fixed 4Max cablelength beeing to short v10b - sidesupport beeing less restrictive for stepper/endstop cable routing v10 - initial release
