Caliper Case

Model details

Platform
Printables
Price
Free
License
CC-BY-NC
Print and modify for yourself with credit; no selling the model or prints.
Formats
STL
  • 9 Likes
  • 45 Downloads
  • 2 Makes
  • 3 Comments
  • 315 Views

Author:BeardWork Designs

Published

Download on Printables

Description

This is a compact tight-fitting case for a Mitutoyo 150mm caliper. It also holds two spare batteries. It can be printed without supports. Print shown was with a generic PLA, .4mm nozzle with .2mm layer height.

For the hinge I designed it to use 4 M4x35 full threaded screws which screw in firmly and provide a firm and reliable hinge.

V02 was added with a slight change to the latch location.

Tags

casemitutoyocaliper
