GUITAR & BASS WALL MOUNT

Follow me for more upcoming designs :)

Description

Guitar or Bass Guitar Wall mount

IDEALLY FOR SYMMETRIC GUITAR HEADS (Fender strats etc will fit but you may get a slight tilt due to the headstock geometry not being symmetrical)

2X Options for slim guitars and thicker guitars like acoustics. Option B is offset another 7mm from the wall.

hidden Screw Design. Fix bracket to wall, then slot mount over

43mm and below necks

- MUST print bracket laying down so layer grain runs the length or the bracket

- MUST print the mount standing up. If not, I can not guarantee the strength of the part. - 0.2 layer height - Minimum of w wall thickness - 30% triangular or Gyroid infill - With the holes, PETG Would be best, but PLA should be strong enough - See the image attached for hole dimensions. I used M4 Screw. Approx 40mm in length - Use suitable wall fixings to avoid failure.
