90deg Corner 1/64 Diecast Car Track - Flat

A 90 degree 1/64 Diecast Car Track, now setup to use traditional connectors - printable in PLA or PETG

PRINT SETTINGS

PETG - 0.18 layer height on 0.6 (or 0.4) nozzle, 15% gyroid infill, 2-3 walls, 2-3 top layers, IRONING ON ALL TOP SURFACES - at the very least for the inverse support pieces (only 1 layer required for walls/top/bottom layers for support pieces). The 0.25mm gap allows twisting and breaking off the support for like materials (Can use PLA as well, but PETG is more flexible). Works pretty well to break off currently.

OR

PLA/PETG Mix - Use the non-banked part and use PLA for the inverse connector pocket bodies. PETG for the main track. I still recommend ironing the top of the supports.

This can fit on an A1 Mini

UPDATE 2025/08/24

Further improvements:

- Flattened the connector pocket

- Added relief for standard 1/64 Diecast Car Track straight connectors

- Again, IRON ALL TOP SURFACES on at least for the support pieces underneath

- Print Profile Added

NOTES

I probably have hundreds of hours perfecting these tracks, with dialed in connector areas and physical printing/testing. No more hokey custom connector pieces. Print with confidence!!

Purchasing

If you don't have a 3D printer and would like to purchase this item, I would be happy to print and ship it to you. Send me a message here on printables. Located in USA but will ship globally if required. Shipping will vary and affect cost.
