Cycloidal Drive 19:1 Reduction

Model details

Platform
Printables
Price
Free
License
CC-BY
Print, modify and use commercially — credit the author.
Formats
STL3MF
  • 13 Likes
  • 167 Downloads
  • 1 Makes
  • 3 Comments
  • 861 Views

Author:Benjamin

Published

Download on Printables

Description

This is a tiny cycloidal drive designed to fit a NEMA17 stepper motor

Reduction: 19:1

The cycloidal ring has been designed to be interchangeable, so if you want to fit a higher/lower ratio cycloidal setup, you only have to print the disk and the outer ring.

Print Details:

Material - PLA

Weight - 22.19 g

Supports - Yes

Print Time - 51 minutes 55 seconds (on Creality K1C printer)

Extra Hardware Needed:

2 x Bearings - 6800-2RS (One for the cycloidal disk and one for the output shaft)

4 x M3 screws (25mm length) … can be shorter if you dont user the spacer
