Garmin Panoptix Live Scope Transducer Tripod and Clip

Model details

Platform
Printables
Price
Free
License
CC0
Public domain: print, modify and sell, no attribution required.
Formats
STL
  • 6 Likes
  • 72 Downloads
  • 0 Makes
  • 0 Comments
  • 1 624 Views

Author:Isaac Sheard

Published

Download on Printables

Description

I printed these in PLA at 20% infill at 0.2 layer height. You will have to use screws to attach the legs to the base of the tripod and a screw so that the clip can hold correctly.

You may have to scale the model up as I had to after exporting the files. The following is what I scaled it to.

Base Tripod=Scale the Z axis to 12.7 mm and turn Uniform Scaling on

Tripod Leg=Scale the X axis to 200 mm and turn Uniform Scaling on

Clip=Scale the Z axis to 12.7 mm and turn Uniform Scaling on
