M10 Screw and Nut – 50 mm Length (1.5 mm ISO Thread)
M10 Screw and Nut – 50 mm Length (1.5 mm ISO Thread) — Image 2 of 2
3D model · Printables

M10 Screw and Nut – 50 mm Length (1.5 mm ISO Thread)

Model details

Platform
Printables
Price
Free
License
CC0
Public domain: print, modify and sell, no attribution required.
Formats
STL
  • 2 Likes
  • 128 Downloads
  • 0 Makes
  • 0 Comments
  • 279 Views

Author:Tim

Published

Download on Printables

Description

This is a 3D printable M10 metric screw featuring a 1.5 mm pitch ISO thread. It’s designed for functional tests, thread calibration, or use in mechanical mockups.

🧰 Best used for:

Thread calibration

Mechanical demos

Lightweight assembly

Prototyping with printed parts

📐 Dimensions

Length (total): 50.0 mm

Thread: M10 × 1.5 (standard ISO)

Head width: ~52.4 mm

Matching nut: M10 ISO (not included)

🖨 Print Settings

Layer height: 0.2 mm

Nozzle: 0.4 mm

Supports: Not needed

Wall count: 3

Material: PLA or PETG recommended

Tags

nutcalibrationmechanicalscrewboltthreadprototypingm10ersatzteilmutterschraubem10nutm10screwm11mechanicalpart
