Voron V0.1 / V0.2 rear panel with better cooling

Model details

Platform
Printables
Price
Free
License
see the platform page
The author sets the terms — check them on the model page before printing for sale.
Formats
3MFF3DSTEP
  • 76 Likes
  • 584 Downloads
  • 7 Makes
  • 10 Comments
  • 4 038 Views

Author:Pix

Published

Download on Printables

Description

Dimensions are 212x248x3mm. You will need a big printer to print this because it didn't fit on MK3/MK4.

Update: Added version with Voron logo. Also added a version with the motor panel attached with 2 screws, the purpose is to better seal the chamber. This version needs 2x inserts and 2x M3x8-12 screws with BHCS (Button-Head Cap Screw).

Based on the Voron V0.1 model from https://github.com/VoronDesign/Voron-0 .

Voron logo comes from https://github.com/VoronDesign/Voron-Extras .

Tags

coolingvoronv01v0voronv01v02voronv02
