Max8 ESC mount for Arrma 4s receiver box

Model details

Platform
Printables
Price
Free
License
CC-BY-NC-SA
Non-commercial use only, with credit; share remixes under the same license.
Formats
STL
  • 3 Likes
  • 25 Downloads
  • 0 Makes
  • 0 Comments
  • 115 Views

This model on other platforms

Author:Kauto

Published

Download on Printables

Description

These adapters will allow you to screw a Max8 esc with no modifications to the top of the receiver box.

If fitting a long motor such as the Hobbywing 4278 to an Arrma Kraton 4s, there is limited space to fit a Max8 esc in front of the receiver box.

The bottom plate screws into the lid of the stock radio box using the stock holes.

The top plate screws onto the stock screw holes on the Max8 using M3x12 countersunk screws, then can be screwed to the bottom plate.
