AM8 Filament Sensor Mount & Guide Ring

These two parts can be fixed to the top side of an AM8 ( https://www.thingiverse.com/thing:2263216 ) aluminium 2020 extrusion frame.

The mount for the filamant sensor accepts two M3 nuts from below and fits any sensor with a 20 mm hole distance, e.g. https://www.amazon.de/gp/product/B07FSXFPLD .

Nuts and bolts needed:

- 2* M3 x ~20 bolt - 2* M3 nut - 3* M5 x ~8mm bolt - 3* M5 2020 slot nut - Some washers if you use longer bolts - Print Settings

Rafts: No

Supports: No

Resolution: 0.2mm

Infill: ≥15%

Filament: Any PLA / PETG

Assembly

Insert two M3 nuts into the bottom hexagonal hole of the sensor mount.
