Anycubic Kobra 2 Max – Manta M5P Controller Board Mount

Upgrade Your Kobra 2 Max with a Powerful Manta M5P Mainboard

This custom-designed bracket allows you to seamlessly mount a BIGTREETECH Manta M5P control board inside the original electronics compartment of your Anycubic Kobra 2 Max. It's a perfect drop-in replacement, designed to utilize the printer's original mounting points for a secure, rattle-free fit without any permanent modifications to the printer's frame.

Why This Mount?

- Precision Fit: Designed specifically for the Kobra 2 Max's stock electronics bay, using the existing screw holes for simple installation.

- Secure Mounting: Provides a stable platform for the Manta M5P board, protecting it from shorts and keeping your wiring organized.

- Optimized for PETG: The model is engineered to be printed in PETG, a material chosen for its excellent thermal resistance and mechanical strength, ensuring the mount won't warp or degrade over time inside the electronics compartment.

- Easy Installation: Uses standard M3 hardware (see below for details). Simply remove the stock board, print the mount, and install the Manta M5P.

Hardware Needed

To complete the installation, you will need the following (not included):

- M3x6mm – 4 pieces (to secure the Manta M5P board to the mount)

Printing Instructions

- Material: PETG (recommended). PLA may not be heat-resistant enough for this application.

- Layer Height: 0.2mm

- Infill: 40% (Gyroid or Grid)

- Perimeters: 4 (for maximum strength)

- Supports: The model is designed to print with supports.
