Adventure Force Axis Switch Pro Collapsible NStrike Stock

Description : A new NStrike stock adapter for my collapsible stock, with a form factor for the Adventure Force Axis Switch Pro, though it will work on most NStrike blasters.

Materials : 4x M3x 6mm Machine Screws 2x 0.16x0.2x0.79 - (0.4*5*20mm) 13 lap springs, but pen springs should also work. Shorter would likly be better. 2x Quick Release Bimini Top Pin Diameter 3/16" (4.8mm), overall length 1.37" (35mm), usable length 0.866" (22mm) * (Optional - a 3d Printed pin exists in the linked Vector Pro stock model)

Printing Instructions : You will need supports. I recommend PETG with 3 walls and 20% gyroid infill, but PLA should be fine.

Stock arms, stock, stock plate, pins, any anything else needed for this are included with my Vector Pro stock. Basically, you just change out the NStrike adapter.

https://www.printables.com/model/1728840-vector-pro-nstrike-pdw-stock-with-spring-latch

https://makerworld.com/en/models/2830476-vector-pro-nstrike-pdw-stock-with-spring-latch

Installation Instructions : 1) Insert the catch into the adapter with the angled catch point facing the blaster. 2) Add 2 springs into the divots in the catch and place the cover with the retention pins in place on the springs. 3) Secure the catch to the blaster with 4 M3x6mm screws. 4) Use it like pretty much any standard NStrike stock.
