ADXL345 Print-in-Place Bed Mount

A simple print-in-place mount for attaching an ADXL345 accelerometer to the printer bed when performing Klipper Input Shaper calibration.

The mount is designed to stay attached to the bed during the vibration test while keeping the ADXL345 securely positioned.

Hardware Required

- ADXL345 accelerometer

- 2× M3×6 screws

- Connecting wires for the ADXL345

Print Settings

- Brim: Recommended - 20mm , 0mm object-brim gap

- Orientation: Print as provided

- Placement: Center of the bed

Installation

- Print the mount with a brim .

- Once printed, attach the ADXL345 to the mount using 2× M3×6 screws .

- Connect the ADXL345 wiring.

- Make sure the accelerometer is securely mounted and that the wiring cannot interfere with the moving parts of the printer.

- Run your Klipper Input Shaper calibration.
