GL-iNET MT6000 / Flint 2 Skadis Mount

For the T-Nuts look at: Skadis T-Nut. By default the holes are made for M2.5 version. There are no embedded alignment guides at the back of model, if you need them use printed ones from Skadis T-Nut Mount Anything on a Skådis Board .

Models have 3 top and 3 bottom M2.5 holes for Skadis T-Nut, I used only top 3 for mounting.

The original model has only holes replaced, the router orientation is the same. There is also flipped model to mount router upside down for more possibilities of cable management if needed (visible on attached images). The flipped model has the router mount points moved down so it aligns with router mounted upside down.

If you need different hole sizes I attached the f3d file, where you can change the hole parameters ( Modify → Change Parameters ).
