Gigi the Giraffe – Low Poly ZOO

Hello, my name is Gigi

A tall, curious low-poly giraffe, built for multi-material FDM printing . About 2 800 flat facets and five colours a golden coat, dark brown spots, a rusty mane running down the neck, a pale muzzle and a tiny black eye.

Every spot is its own set of flat facets, so the pattern prints crisp and clean instead of fuzzy, no tiny colour changes inside a facet.

Gigi joins my Low Poly ZOO series - a collection of animals made in the same style, scale and colour language, so they look good together on a shelf.

What you get

Three pre-painted project files with the colours already assigned as MMU painting. Open the one for your printer in PrusaSlicer, load your filaments and print, no manual painting needed.

- Giraffe_CORE_One_INDX_8T.3mf — Prusa CORE One INDX, 8 tools — all five colours

- Giraffe_XL_5T.3mf — Original Prusa XL, 5 toolheads — all five colours

- Giraffe_CORE_One_INDX_4T.3mf — Prusa CORE One INDX, 4 tools — four colours: the black eye and the rusty mane join the dark brown

On a printer with two tools, print the body and the spots, and leave the muzzle, mane and eye in the body colour - the spots are what makes it a giraffe.

Recommended filaments

Prusament PLA: a golden yellow for the coat , Noctua Brown for the spots, hooves and tail tuft, a warm rust or terracotta for the mane , Noctua Beige for the muzzle and Jet Black for the eye . Any colours work — the facets do the heavy lifting.

See it before you print it

Preview3D opens 3D models and G-code the way Quick Look opens a PDF -on a Mac, an iPad, an iPhone and Apple Vision Pro.

Point your camera at the code and this giraffe stands on your own table in AR, at the size it will actually print. Nothing to install: it opens as an App Clip, shows the model, and leaves.

Check the fit before the filament. See how big a print really is next to the shelf it is meant for.

Open what can't preview. STEP , painted 3MF , STL , OBJ , glb , glTF , FBX and about a dozen more - plus G-code with a layer slider.

Thumbnails in the Finder and Files, so a folder of downloads stops looking like a folder of blank pages.

Publishing a model yourself? Make the same animation for it at preview3d.xfanta.com/qr - paste your model's link and get a QR code and a ready-made GIF for every file in it. Free, and it runs in your browser.

Print settings

- Size: about 27 × 75 × 120 mm as delivered (width × length × height)

- Layer height: 0.2 mm (0.15 mm if you want smoother facets)

- Nozzle: 0.4 mm

- Infill: 10–15 %, any pattern

- Supports: only about 6 % of the surface overhangs. Let PrusaSlicer add organic supports where it suggests them; they leave almost no marks on the flat facets.

- Orientation: as in the 3MF, standing on its four hooves. The contact area is small (about 70 mm² in total), so use a brim — it comes off the flat hoof faces cleanly — and avoid fast travel moves near the top of the neck.

- Scaling: delivered at 120 mm tall. The thinnest parts are the legs, the tail and the tips of the horns, so don't scale it down; scale up freely.

Show your print

The colours are yours to play with — a white okapi-style giraffe, a pink fantasy one, or just one colour and let the facets do the work. Post the result as a Make under this model; I'd love to see the colour combinations you come up with, and the best ones get featured here.

Please don't re-upload the model itself: recoloured copies published as new models (here or elsewhere) aren't allowed.

More animals from the ZOO series are coming — follow if you want the whole herd.
