1" Diameter Knurled Knob for 1/4x20 nuts and bolts

Model details

Platform
Printables
Price
Free
License
CC-BY-NC
Print and modify for yourself with credit; no selling the model or prints.
Formats
STL
  • 31 Likes
  • 225 Downloads
  • 5 Makes
  • 5 Comments
  • 861 Views

Author:Frugal Shave

Published

Download on Printables

Description

Knurled Knob for 1/4x20 nuts and bolts.

I really like the feel and grip of the knurled knob, and it has a smaller footprint than wing knobs. This is perfect for woodworking jigs that use T-track

1" outer diameter, fits the 7/16" head on a standard 1/4"x20 nut and bolt.

Designed for a tight pressure fit. You will need pliers to insert the nut.

I printed with 3 shells and 20% infill for some extra strength.

Category: Hand Tools
