Seckit Sk-go ABL Inductive Pinda mount (M8)

Pretty straight forward thing, you need one M3 nut and bolt to mount it.

Probe position is #define NOZZLE_TO_PROBE_OFFSET { 20, 10, -0.9 }

To setup your probe, move the nozzle until it touches the bed, put a ziptie between the probe and the bed tighten the probe nuts.

-0.9 is right on and I only adjust a couple hundreds, You can use -0.8 for your offset if you want to be on the safe side, use babystepping/ liveZ to fine tune your squish at the beginning of your print.

It's obviously best to print this mount in ABS since it's close to the heater bloc.

Print Settings

Printer Brand:

Prusa

Printer: I3 MK3S

Rafts:

No

Supports: No

Resolution:

0.2

Infill: 20%

Filament: Coex ABS White

Category: 3D Printer Parts
