Sapphire Pro Robin Nano 80mm Fanmount

Model details

Platform
Printables
Price
Free
License
CC-BY-NC
Print and modify for yourself with credit; no selling the model or prints.
Formats
3MF
  • 11 Likes
  • 56 Downloads
  • 0 Makes
  • 0 Comments
  • 685 Views

This model on other platforms

Author:Tobiwan80

Published

Download on Printables

Description

I have remixed a Model from Thingiverse to use a 80mm Fan for Stepper Driver Cooling and reducing Fan Noise on my Sapphire Pro. I have used this 80x80x10mm 24V Fan wich is really quiet in my opinion. I glued in the m3 nuts to attach the fan after mounting the frame.

The 2 legs on the Wall side (right side on the Picture are shorter by 1mm, its not needed to screw in all 4 Screws. I have used 2 M3x40 Screws for replacing the 2 Mainboard Screws.

The Modell is a Remix from Thingiverse.com

Tags

fanmountfanadaptersapphireprorobinnano
