Arduino DIN case

Model details

Platform
Printables
Price
Free
License
CC-BY
Print, modify and use commercially — credit the author.
Formats
STL
  • 18 Likes
  • 155 Downloads
  • 0 Makes
  • 3 Comments
  • 1 252 Views

Author:Feken

Published

Download on Printables

Description

I needed a DIN case that would fit an Arduino UNO, LCD, Arduino shield and a Solid state relay. So I took this https://www.thingiverse.com/thing:3402441 one and altered it a bit.

Things changed:

- Moved Arduino to right to make room for shield

- Made it bigger (7 units)

- Removed fan

- Added mounting for Solid state relay

- Moved cable in

- Other small improvements

Print Settings

Printer Brand:

Prusa

Printer: i3 MK3

Rafts:

Doesn't Matter

Supports: Yes

Resolution:

0.2

Filament:

Amazon PETG

Category: Electronics
