Logitech C920/C922/C930/Brio/Miro Moment-style lens adapter

If you have old smartphone mobile lenses and want to use them to change up or enhance your existing webcam, these clip in place adapters will allow any bayonet-style lens to mount firmly against the webcam. Add barrel distortion, chromatic aberration, lens flare, bokeh, and other artistic imperfections without having to connect and mount a larger, more expensive camera. These will not, however, improve your webcam's noise or low-light performance.

The adapters can be printed without support when placed on their side if your printer performs well with bridges and overhangs. Both adapters feature a small angle for clamping force and to avoid slipping. Adapter B features a small cutout to not block the IR sensor.

Without a lens mounted, the adapters are only minimally visible in the corners of the frame (I recommend printing in black, so it acts as a pseudo-vignette). They can also be moved over slightly to act as impromptu privacy covers.

Printed at:

- .2mm layer height and a .4mm nozzle on an Ender 2 Pro using PLA - .25mm layer height and a .5mm nozzle on an Ender 5 Plus using PLA Tested and confirmed working lenses:

- Moment Wide 18mm Lens - Moment Tele 58mm Lens - Moment Anamorphic Lens - SIRUI 18mm Wide Angle Lens Supported Webcams (Adapter A):

- Any Logitech C920/922/930 variant Supported Webcams (Adapter B):

- Logitech Brio - Logitech Miro
