M5-sockethead thumb screw

Model details

Platform
Printables
Price
Free
License
CC-BY-SA
Print, modify and sell with credit; share remixes under the same license.
Formats
STL
  • 1 Likes
  • 43 Downloads
  • 0 Makes
  • 0 Comments
  • 302 Views

Author:jubs

Published

Download on Printables

Description

Customized version of https://www.thingiverse.com/thing:45117

Created with Customizer! https://www.thingiverse.com/apps/customizer/run?thing_id=45117

Instructions

Using the following options:

Knob_Type = 3

Thread_Size = 5

Knob_Fill = 3

Knob_Diameter = 40

Knob_Thickness = 10

Wall_Thickness = 4

Number_of_Rosettes = 6

Rosette_Radius = 6

Rosette_Offset = 3

Chamfer_Size = 1

Category: Hand Tools

Tags

thingiversecustomized
