Simple Volume Knob

Model details

Platform
Printables
Price
Free
License
CC-BY-NC
Print and modify for yourself with credit; no selling the model or prints.
Formats
STEP3MFSTL
  • 6 Likes
  • 208 Downloads
  • 1 Makes
  • 1 Comments
  • 1 702 Views

Author:Youenn Troalic

Published

Download on Printables

Description

I have designed this volume knob to fit in my minimalistic setup (It looks very nice in coffee and black PLA)

It is useful when playing music or videos

All the code and tutorial is available on prusaprinter.org

--> https://blog.prusaprinters.org/3d-print-an-oversized-media-control-volume-knob-arduino-basics_30184/

Print Settings

Printer:

Intersystem V1 (custom 3d printer)

Resolution:

0.12 / 0.2

Infill:

18%

Filament:

Francofil PLA

Coffee biosourced and black

Notes:

Supports are not needed for the base, I have added chamfers.

Mounting instructions

Place the arduino in the base and screw the encoder to the top part then glue it to the base. Finally you just have to friction fit or glue the encoder to the big knob.
