Protective Face Shield Hyper-Speed Remix - RC3HX 5mm

Model details

Platform
Printables
Price
Free
License
CC-BY-NC
Print and modify for yourself with credit; no selling the model or prints.
Formats
STLGCODE
  • 0 Likes
  • 595 Downloads
  • 0 Makes
  • 15 Comments
  • 1 966 Views

Author:Makers Guild

Published

Download on Printables

Description

5mm design update from the previous high-speed remix - RC2X

Currently in use at GP surgeries around Portsmouth, UK and community keyworkers. We are producing about 100 a day on 4 printers

Revision 1

• Modified width to be compatible with standard Ender 3

Key difference with RC3

• 5mm total height

• Optimised for speed: about 30 minutes to 1 hr each

• Adapted to fit A4 or A3 sheets, with no changes in dimensions of RC3

• Experimental stacking: tested 20 batches

Files

Stack of 6: estimated print time 5 hours (record: 3 hrs)

Stack of 11: estimated print time 9 hours (record: 6 hrs)

Only print the stack of 11 if your printer is enclosed and highly tuned. Higher risk of delamination 6 and above.

Only print at 0.25mm layer height. Any other layer height will result in a fused solid print.

Print instructions

0.25mm Layer Height

3 Perimeters

No Supports

4mm Brim or 1 Layer Raft
