Voron Trident / 2.4 X-Carriage Square Nut + Euclid Mod

Model details

Platform
Printables
Price
Free
License
see the platform page
The author sets the terms — check them on the model page before printing for sale.
Formats
STL
  • 12 Likes
  • 68 Downloads
  • 2 Makes
  • 2 Comments
  • 1 504 Views

Author:Shai

Published

Download on Printables

Description

Basically this is a “Merge” of two great mods:

https://www.printables.com/model/247694-voron-24-x-carriage-frame-square-nut-mod

https://www.teamfdm.com/files/file/554-sb-x-carriage-euclid-probe-24trident-mgn-12/

I liked the idea to use the Euclid probe without any adapter, but had the same issue with the lower heat inserts in the X Carriage, so I decided to create a merged version, supporting both.

Use default Voron Settings to print, insert M3 square nuts on lower end. Euclid probe is mounted using M3x8mm self taping screws.

Trident with Dragon HF, I'm using the following settings, but please verify for your own build.

[probe] x_offset: 2 y_offset: 21 z_offset: 4.5

Tags

xcarriagetridentvoronvorondesignvoron24vorontrident
