Bigtreetech SKR E3 Mini + Rasperry Pi 2/3 + 3 LM2596 + Noctua Fan Enclosure for Ender 3/Ender 3 Pro

Model details

Platform
Printables
Price
Free
License
CC-BY
Print, modify and use commercially — credit the author.
Formats
STL
  • 33 Likes
  • 159 Downloads
  • 1 Makes
  • 4 Comments
  • 2 024 Views

Author:LoK

Published

Download on Printables

Description

This is an Electronics front enclosure for Ender 3/Ender 3 Pro, it is designed to fit:

Bigtreetech E3 Mini

Rasperry Pi 2/3

4x LM2596

1x Noctua Fan 40x40

The design has been splitted in 4 parts, use selftapping screws 2.5 x 15 mm to join the parts and 2.5 x 5 mm to fix the electronics

If you like my design you can offer me a coffee: https://www.paypal.me/gabercole

Print Settings

Printer Brand:

Creality

Printer: Ender 3

Rafts:

No

Supports: No

Resolution:

.24

Infill: 25%

Filament: Sunlu PLA + Black

Category: 3D Printer Accessories
