Arduino Mega DIN rail mount

Model details

Platform
Printables
Price
Free
License
CC-BY-NC
Print and modify for yourself with credit; no selling the model or prints.
Formats
STL
  • 79 Likes
  • 1 076 Downloads
  • 10 Makes
  • 11 Comments
  • 3 589 Views

Author:KaosuNeko

Published

Download on Printables

Description

Arduino Mega (and all compatible shields) DIN rail mount

Compatibility:

Arduino Mega 2560 Arduino Mega 2560 + Wi-Fi

35mm DIN rail

Mounting components:

M3 screws M3 stand

More DIN rail mount design:

Thanks to Bilal for making a Arduino Mega model.

If there are any licensing restrictions, please contact us (This model is used for rendering only, measurements taken from real product and datasheet).

Category: Electronics

Tags

arduinothingiversedindinraildinrailmountarduinoshieldarduinomega2560arduinomega
