Mosaic Palette 3 Wall Mounting Bracket

Model details

Platform
Printables
Price
Free
License
CC-BY-NC
Print and modify for yourself with credit; no selling the model or prints.
Formats
3MFSTLSTEP
  • 11 Likes
  • 103 Downloads
  • 0 Makes
  • 9 Comments
  • 581 Views

Author:Stewart MacLund

Published

Download on Printables

Description

Designed to allow full insertion of the bracket upside down with the corner cutout (the P3 has some internal steel bracketing that doesn't allow the normal stand profile to insert fully), and a small standoff supporting below the bracket so the Palette doesn't appear to sag. Designed for #12 screws, #14 fit.

Needs no brim, printing with the shallow angle down and the long axis aligned with Y.

I printed with 0.8 nozzle, 0.4 layers, 0.3 Elephant foot compensation, Filaments.ca PLA PRO.

Shown using RepRack filament system for feeding.

v1.1 has some incremental changes to pull the P3 closer to the wall and adds a positive stop to the bracket so that it doesn't “wiggle” on the mount. Very solid now.

Tags

mosaicpalettemosaicpalette3promosaicpalette3
