PS4 thumbsticks

This is a remix of thumbsticks for PS4. My son needed them to play Fortnite, and they seem to work well for him.

The top parts of the thumbsticks are remixed from PS4 Thumbstick Mods by philbarrenger .

Top parts have to be printed with flexible plastic, like FLEX. Also, set the fill density at about 40% (print quality degrades for smaller values).

The bottom part is remixed from PS4 thumbstick extenders - library of options by ScottBob214 , and can be printed from ABS or other non-flexible plastic.

The fill density doesn't matter a lot there, I have used 15% when printing.

Print Settings

Printer:

RepRapPro Mendel

Rafts: No

Supports:

No

Resolution: 0.3

Infill:

40% (top parts), 15% (bottom parts)

Filament:

https://3dplast.biz/ FLEX (top parts), ABS (bottom parts) Post-Printing =============

- Glue left thumbstick bottom part (ps4-left-bottom.stl) with left thumbstick top part (ps4-left-top.stl).

- Glue right thumbstick bottom part (ps4-right-bottom.stl) with right thumbstick top part (ps4-right-top.stl).

- Push fit the printed thumbsticks over the existing PS4 thumbsticks.
