My Customized Parametric Herringbone Gear Set for Stepper Extruders

Customized version of http://www.thingiverse.com/thing:6544

Created with Customizer! http://www.thingiverse.com/apps/customizer/run?thing_id=6544

Instructions

Using the following options:

distance_between_axels = 60

gear2_captive_nut_h = 0

gear2_captive_nut_d = 0

AT = 0.02

gear1_setscrew_offset = 5

gear2_shaft_d = 8.5

gear2_setscrew_d = 0

gear1_shaft_d = 5.25

gear2_setscrew_offset = 0

gear2_cut_circles = 8

gear1_teeth = 13

gear1_setscrew_d = 3.5

gear_h = 15

gear2_shaft_outer_d = 21

generate = 0

bridge_helper_h = 3

gear2_rim_margin = 0

gear2_bolt_sink = 15

gear_shaft_h = 15

gear1_captive_nut_h = 3

gear1_captive_nut_d = 6.2

gear2_bolt_hex_d = 15

gear2_teeth = 51

Category: 3D Printer Extruders
