Meanwell UHP-350-xx Single & Dual DIN Rail Mount
Meanwell UHP-350-xx Single & Dual DIN Rail Mount — Image 2 of 2
3D model · Printables

Meanwell UHP-350-xx Single & Dual DIN Rail Mount

Model details

Platform
Printables
Price
Free
License
CC-BY
Print, modify and use commercially — credit the author.
Formats
3MFSTEP
  • 53 Likes
  • 410 Downloads
  • 4 Makes
  • 7 Comments
  • 2 114 Views

Author:mmuellerphoto

Published

Download on Printables

Description

This is a C-LIN SSR 40A480VAC Mount for my DIN Rail Bracket. You can find the bracket here !

For the Mount you need M3 screws and M3x4 or M3x6 Heat Inserts.

For the DIN Rail Bracket Mount you need M3 countersunk screws.

“Single” and “Dual” Version.

2023-05-18: Low profile version added - no need for additional DIN Rail Bracket

Tags

mountmeanwelldinrailuhp350uhp
