Clamp wall, Parametric

3D printed parametric wall clamp for pipe, Default diameter 32mm

Manufacturing procedure:

- Material: PETG (possible alternatives ABS, ASA, PC, PA11), not recommended PLA - 3D Printer: FDM 3D printer, average print time 30 – 60 minutes, depending on parameters - Slicer settings: 4 perimeters, 0.2mm layer height, print in the position where the clamp is lying on the print bed to increase the strength and adhesion to the print bed - Post processing instructions: Clean the stringing, check clearance of the screw - Assembly instructions: Use the screw (default diameter 4mm) to mount to the wall, insert pipe Following parameters can be adjusted using Autodesk Fusion 360:

- PipeParameter - Enter value from 20mm to 40mm, for higher or lower values the right geometry might not be generated. - ClampThickness - Enter value from 12mm above - Clamping Angle - Enter value from 60 to 150 degrees. - ScrewDiameter – Enter value according to the used screw with 0.1-0.3mm more for tolerance - ScrewHeadDiameter – Enter value according to the used screw with 0.5- 1mm more for tolerance - DistanceFromWall - Distance of Pipe diameter from the wall
