Scope Rings for Talon Claw

I had trouble finding scope rings that were tall enough to use with my Talon Claw with the IVI Talon Claw 4 Skeggox Stock ( https://www.thingiverse.com/thing:5163077/comments ), so I designed my own. These rings are 1.6inch from the top of the Picatinny rail to the center of the scope, which is exactly right for me to get a solid cheek weld without having to smash my face through the stock. I printed it with the top facing upright (with supports), and the other pieces on their sides, but I'm sure you could get away with just about any orientation. It uses M3 bolts (2 long (~30mm) and 4 short (~10mm) per ring) and M3 hex nuts (6 per ring). It probably doesn't provide as much clamping force as a fancy aluminum ring, but you could always slap some electrical tape on the inner face of the ring if you're dissatisfied with the clamping. I didn't find that I needed that.

It'd probably work with most Picatinny rails, but I modeled it specifically with the Talon Claw T4's rail model, so I only know for sure that it works with that.
