Red Dot Finder Mount - Astro Dovetail to NATO/Picatinny Rail

Model details

Platform
Printables
Price
Free
License
CC-BY-NC-SA
Non-commercial use only, with credit; share remixes under the same license.
Formats
STL
  • 5 Likes
  • 66 Downloads
  • 2 Makes
  • 2 Comments
  • 875 Views

Author:Bike Cyclist

Published

Download on Printables

Description

Red Dot Sight Adapter - Astro Dovetail to NATO Rail

To be mounted in Astro dovetail shoe with 34 mm base.

(Foot has 32.5 mm base width and 60 degrees flank angle.)

Provides NATO/Picatinny/Weaver-compatible rail for mounting a standard red dot sight (reflex sight) or a standard target scope to the telescope.

Includes FreeCAD source file in case you'd like to modify the mount
