Improved Auto Coin Sorter - Coin Roll + Classic Version

New in latest version 7.527:

- Improved geometry to increase reliability and accuracy of the sorting.

Improvements:

- Sorts into removable coin tubes to facilitate both general operation and coin-rolling

- (Or use customizer to make a version with the "classic" simple slots)

- Simple and robust lid-type top board that stays perfectly aligned and keep the coin holder reliably in place, too.

- Extra length of coin ramp to make feeding the sorter easier

- Options for raised guard rail and for rear guard rail to facilitate quick and reliable feeding of coins

- Tubes easy to print and marked at the bottom to keep them apart easily

How to use

An automatic coin sorter for many currencies. See also http://youtu.be/7F2fIF9PNBk for a short demo video of the original version.

To store a coin, you may release a coin from the rightmost top, and it will slide down the hill and go into the appropriate tube.

Once a tube is full,

- remove the top board of the sorter,

- take out the tube, roll into into a paper wrapper,

- fold the wrapper over the open end of the tube,

- pull the tube out of the wrapper, leaving the coins in the wrapper,

- fold over the other end of the wrapper - voila, there's your easy coin roll!

- Re-insert tube and carry on sorting.

Printing

All parts can be easily printed without supports, with the sole exception of the top board.

The top board can be printed either:

a) with supports b) split vertically so that you have two parts that print without supports, then glued together.

The top board might need to be oriented diagonally to make best use of the available print surface.

The EUR version will fit on a 210 mm x 210 mm print bed. All others are smaller, except for the PLN version, which will require a reduced top board extra length.

New in V7.4: The basebox can be printed upright, which is quicker, uses less material and makes it fit on smaller print beds.

Currencies

List of Available Currency Versions ("*" denotes variants being available):

- ARS - Argentine Peso

- AUD - Australian Dollar

- BGN - Bulgarian Lev

- BRL - Brazilian Real

- CAD - Canadian Dollar (2 versions: with/without $1/50c)

- CHF - Swiss franc

- CLP - Chilean Peso (2 verions: pre-2012 coins included/post 2012 coins only)

- CZK - Czech Koruna

- DKK - Danish Krone

- EUR - Euro

- GBP -British Pound
