Dual Extruder XY Calibration Quick Print

This is a XY calibration file designed to be quick to print to make many revisions possible in a short amount of time.

The two colors are printed on top of one another to only have a single tool change

The file should be very easy to read and self explanatory even after removing from the bed to take measurements and check layers. I had found some other files to be alright but always lost what axis needs adjustment after the print has been removed.

Print Settings

Printer:

Modded Kodak Portrait Duet3

Rafts: No

Supports:

No

Resolution: 0.2mm

Infill:

n/a

Filament:

n/a n/a n/a

Notes:

Print using 0.2mm layer height. The total

model height is 1.2mm, 3 layers per color.

When slicing, pay attention to your X

and Y axis and position accordingly on

print bed for proper orientation to

aid in diagnostics.

Category: 3D Printing Tests
