ChromaSnap - Dry Erase Marker Holder For Whiteboard

Motivation:

I saw many bulky clips for whiteboard markers and chose to design something more visually appealing.

Features:

- Vertical and horizontal storage is possible - Neodymium magnets Ø10x3 mm or smaller magnets or M4 screws can be used - Utilizes minimal materials - Markers can be stored with the cap up or cap down - Markers snap securely in place - very satisfying :) - Requires a diameter around ⌀16,3 - 17 mm for vertical storage - New: STL for ⌀12 mm My Print Settings

Magnets:

- Utilize neodymium magnets Ø10x3 mm or smaller - Incorporate filament change for the final open slice for magnet insertion Brim: No

Supports: No

Resolution: .2 mm

Infill: 15%

Filament: Any PLA or PETG

Some Notes:

I've tested the ⌀16,3 mm version with STAEDTLER whiteboard markers. It should also be compatible with expo whiteboard markers. Welcome improvement suggestions and other diameters in comments :)

Your insights are welcome <3

Change log:

- (25 -08-2023 ) – Added STL versions for attachments with screws. - (16 -12-2023 ) – Fixed confusing description - (19 -03-2024 ) – Enhanced reconstruction of the Fusion file for simplified adjustments of diameter and pen settings; also introduced a 12mm version for markers such as Edding 361
