Step Down Buck Board Voltage Converter Upgrade for Prusa i3 MK3 MK3s

Model details

Platform
Printables
Price
Free
License
CC-BY-NC-SA
Non-commercial use only, with credit; share remixes under the same license.
Formats
STLSTEPF3DGCODE
  • 23 Likes
  • 104 Downloads
  • 1 Makes
  • 5 Comments
  • 1 717 Views

Author:mcfada

Published

Download on Printables

Description

This cover clips into the Einsy case and supports a buck converter board. Wire the board input into your 24V power terminals on the Einsy, and set to 5V and wire the output to a Raspberry Pi 3 B+ or 4.

Print instructions

PARTS

LM2596 DC-DC Buck Converter

M3 Nylon Black Hex Screw Nut Standoffs

This and some wire and the cover is all you need to bring the buckboard onto your printer. You can use this to power any peripherals up to the power draw of your buck converter. I chose to power a Raspberry Pi 3 b+ and TFT Touchscreen running Octoprint, pictured.
