Ender 3 V3 SE 4010 Fan Shroud

MK15.1 is the latest and suggested version to use, the other versions may not work as expected but have been left here for users that already have the previous versions and want to print it again.

Hexagon Pattern can be printed with two different colours which looks cool

You will need both the shroud and the duct, the duct only needs support under the screw loops, make sure none of the supports are inside the duct.

Printed at 0.2mm layer height and 3 walls/perimeter's.

Can be printed in PLA, excluding the new MK4 Fan duct which needs to be printed with PETG or ABS. I don't have any PETG/ABS on hand so don't know how well it prints but with PLA the shroud warps as it is close to the silicone sock on the hotend.

Uses the original screws that came with the printer.

Voron design is there due to me waiting to build mine :) - update its built :p
