Din Rail to Extruded Aluminum quick test piece

Model details

Platform
Printables
Price
Free
License
CC-BY-NC
Print and modify for yourself with credit; no selling the model or prints.
Formats
STL
  • 16 Likes
  • 89 Downloads
  • 0 Makes
  • 0 Comments
  • 796 Views

Author:NotLikeALeafOnTheWind

Published

Download on Printables

Description

Ok, this is a strange one. (Even for me.) This is a din rail mountable small block of 8020 series 10 compatible beam. I use it for attaching displays that were designed for the extruded aluminum system to a din rail. (This keep me from having to design and print a lot of single use parts.)

You will need to print one tabs for this design.

They can be found at: https://www.thingiverse.com/thing:3401942 or https://www.prusaprinters.org/prints/8512-din-rail-mounting-tab

Print Settings

Printer Brand:

Prusa

Printer:

I3 MK3S

Rafts:

No

Supports:

No

Resolution:

200

Infill:

20

Filament: Inland PLA Black

Category: Electronics
