TrackTwist socket holder organizer 3/4" 1/2" 3/8" 1/4" drive SAE METRIC gridfinity V2 Wrench and tool organizer

Updates

- updated rails to be .5mm shorter for gridfinity and for tighter magnet fitting 24.6mm and 2.8mm deep.

- added V-style holder for ratchets and large extensions 8/17/2024

- 3-4 inch drive tool and socket holder and washers 2/18/2024

- changed tool holders to double as wrench organizer 2/18/2024

- uploaded washers for wrench organization.

- 3/8 inch holder compatible with same rail for compatibility

- reduced profile to accommodate up to 3.25 inch deepwell sockets in a common 4 inch drawer

- Fillets!

- Diverted from t-slot profile to reduce height of design and filament usage

- Integrated gridfinity profile

TrackTwist Socket Organizer

After investing considerable time researching various socket organizers on the market, I found myself consistently disappointed with their quality and the often high costs associated. This realization led me to design the TrackTwist Socket Organizer . Combining functionality with open-source principles, this organizer was conceived out of a pressing need for an improved storage solution.

Features:

Twist Lock Mechanism: The innovative twist-lock design ensures that sockets remain securely in place, even when dropped.

Modular Setup: Compartments can be tailored and rearranged to align with your specific socket collection and preferences.

Clear Size Markings: Each holder spotlights multiple size indicators, guaranteeing visibility from every angle. Say goodbye to the frustrating search for the right socket size.

Open-Source Design: Adaptability takes center stage. This organizer invites users to modify and adjust based on their specific needs and feedback.

Extensible: With the ability to create mounts, attachments, and end brackets, you can expand the organizer's capabilities as you see fit.

Durable Materials: Crafted with resilience in mind, it's primed to accommodate an assortment of socket weights and sizes without wavering.

Compact: Prioritizes efficient storage while minimizing spatial footprint.

TrackTwist Socket Organizer rectifies common issues inherent to existing organizers, showcasing a more malleable and user-oriented approach to socket storage. It's the go-to for those scouting a practical and adaptable tool storage mechanism.

Under construction — stay tuned for more sizes, attachments, and options in the pipeline!

Create your own custom washers using Prusa Slicer

I've uploaded a 60 washer of varying width. Don't see the text you want or need something custom engraved for a specialty socket or tool? You can use Prusa Slicer to engrave your own text! Font is Calibri Bold. Follow the instructions here: https://help.prusa3d.com/article/text-tool_399460

If you don't have a printer profile setup in prusa slicer no worries! Just add your text and save it as an STL and import into your regular slicer.

Magnets

25x3mm magnets. ~1" should work be sure to by neodymium magnets not ferrite

https://www.amazon.com/Caturledas-Strong-Neodymium-Magnets-Kitchen/dp/B0FDQJGS24/ref=sr_1_2?crid=3F0XHWCALP7YE&dib=eyJ2IjoiMSJ9.5ieYfx2ayg1KbiqeBKDvLst9pUE3w3wT0VtV1KdbTa8zHx9EKcu7smbRKO03Xw7XWwhl8X60ATyRQc_hw0P--Gog97uU3OjcbYSbhR96Pbb8N4xT-BpwruiuXImQcGkY5dMZhiW3Z4XBsmsv7dzD7e-uksHE2OBeFm8wgosjiLKEUkfBFuqKm8eYZj-hVnxMuRHo8OzwOO7NpOIt_IFOVduGqSsnT5IkfFTQ8wFZXui1ICmmTL4oJ9Rk9evPjWDiLvxpacz8JgwlfEb7uAyJUHebDdEUi012yNpEKZPPgyc.s434cMlz2-fIX_6h1jjKOI9yi1cMbbX9jBbxPw_3wXk&dib_tag=se&keywords=25x3mm&qid=1776572215&s=industrial&sprefix=25x3mm%2Cindustrial%2C249&sr=1-2&th=1

If you dont see a washer size on here that you need, or they dont work for you please reach out and ill see if I can generate the correct sizes you need. Use appropriate washer for IMPACT or regular walled sockets. Sizes should work for multiple Name brand and off-brand sockets.

Print Settings

Rafts:

No

Supports:

Yes

Resolution:

.2

Infill:

50%

Filament: Any PLA,PETG,ABS,ASA,PC
