Voron 0.2 - HBV1313 Camera mount

Model details

Platform
Printables
Price
Free
License
CC-BY-SA
Print, modify and sell with credit; share remixes under the same license.
Formats
STL
  • 12 Likes
  • 95 Downloads
  • 0 Makes
  • 0 Comments
  • 782 Views

Author:Screase

Published

Description

Just a little camera housing to fit a HBV1313 PCB with OV2659 chip onto the right side of any Voron 0.1 / 0.2 extrusion without preloaded nuts.

Due to easy printing the 2x clips have to be glued onto the slots at the upper side of the casing.

Credits for the clip goes to @ibash158169 https://www.printables.com/model/130955-clip-for-1515-extrusion/files

Screw the backplate with 2x M2x6mm screws together, glue to two clips into place and clip it into the 1515 extrusion!
