Box for DJI Mini 4 Pro and accesories

Introducion

The compact and lightweight design of the Mini 4 Pro makes this drone great for travelling. Sadly, there was no safe way to transport it - until now!

The Basics:

The complete set contains three types of boxes. They are designed to fit all essential components of the fly more combo kit. There is…

…a Box fitting the Drone (DJI Mini 4 Pro)

…a Box fitting the Remote (DJI RC2) and the DJI ND Filter set

…a Box fitting the two remaining flight batteries

Update log

Update #1

- Added the .STEP files (as requested by @JeanBrito).

Printing and Assembly

You have the choice:

There are three options available for printing.

- Option 1 : You are here for functionality and simplicity? This is the option for you! Both halves of the boxes are printed as a single piece. This option is the easiest to print while using less time and material . - Option 2: You are ready to accept using a bit more effort and material to get a great looking part ? You might want to go for this option! Both halves of the boxes consist of two parts. That allows a multicolored part - without using an multi-material printer. (You can find detailed informations on how to print below.) - Option 3: You want to go all in for that extra bit of detail ? You are ready to dive into the advanced settings? Here comes option three! This option is basically the same as option two. Additionally there is a littel symbol “engraved” on the top of each box that shows whats inside of it. (Informations on how to print are also listed below.) You found an option that fits you? Great! Let's start printing!

Printing

Required parts:

If you use 1.75mm filament you already have everything you need. If not, I'm sure you can find something with that diameter at home or in your local hardware store.

Here's an overview of which parts you need, depending on your chosen option:

Main Parts by option

Option 1 1x box-XXX-bot_ SINGLE .stl Box; bottom

1x box-XXX-top_ SINGLE .stl Box; top

Option 2 1x box-XXX-bot_ 2-PARTS .stl Box; bottom

1x INLAY -XXX-bot.stl

1x box-XXX-top_ 2-PARTS_BLANK .stl Box; top

1x INLAY -XXX-top.stl

Option 3 1x box-XXX-bot_ 2-PARTS .stl Box; bottom

1x INLAY -XXX-bot.stl

1x box-XXX-top_ 2-PARTS_ENGRAVED .stl Box; top

1x INLAY -XXX-bot.stl

1x box-XXX_engraving.stl

Additional parts by type of box

clip.stl lever.stl hinge.stl bushing.stl

Drone 2x 2x 3x 16x

Remote 2x 2x 3x 16x

Battery 1x 1x 1x 6x

Print settings:

Layer heights over 0,2mm are not recommended, everything else is up to you. There are no supports needed.

Printing the 2-part version:

Slicing:

As mentioned above, in this option the boxes consist of two parts. First, print the parts INLAY-XXX-bot and INLAY-XXX-top . Later the inlay parts are going to get embedded when printing the parts box-XXX-bot_2-PARTS and box-XXX-top_2-PARTS .
