O' RIDGE | Floor lamp E27 fast print

O' RIDGE | Floor lamp E27

Give your space a modern mid-century vibe with this fast-print O' RIDGE floor lamp!

It is the big brother of the DELTA RIDGE Table Lamp .

The shade and base are each made of two thin shells that join at the top and bottom, casting a warm & soft - but still very bright - glow. They both print very fast with the right settings listed below. The shade takes about 3.5h, and the stand less than 2.5h.

The hole at the center of the fastening bracket is for a standard E27 socket screw. Hole diameter: Ø41mm

On the pictures, I'm using the IKEA NYFORS lamp stand, because the shade broke and I had to make a new one. You could also use the SKAFTET lamp stand, which can be purchased on its own without a shade.

Happy printing!

DIMENSIONS | Ø250 mm x H 180 mm

PRINTING | Shade ~3.5h | Stand ~2.5h

Bulbe socket | E27

3D PRINT SETTINGS: All STL files are already oriented properly.

You need to print 2 parts: • 1 lamp shade • 1 base/stand.

They can be printed with either a 0.4mm or 0.8mm nozzle. The 3D model is full. This is normal. You need to "empty it" by printing it vase mode (spiralize outer contour / spiral vase).

For 0.8mm nozzle: • 0.3mm layer height • default 0.84mm up to 1mm line width (for default and outer wall) • 4 bottom layers (adjust if using another layer height)

For 0.4mm nozzle: • 0.2mm layer height • 0.8mm line width (for default and outer wall) • 6 bottom layers
