ENDER 3 V3 SE 5020 FAN DUCT

Model details

Platform
Printables
Price
Free
License
CC-BY-NC-SA
Non-commercial use only, with credit; share remixes under the same license.
Formats
STL
  • 41 Likes
  • 220 Downloads
  • 1 Makes
  • 12 Comments
  • 2 935 Views

This model on other platforms

Author:MD_CAD_Creation

Published

Download on Printables

Description

This is a Remix Of the 5015 version. I made it compatible for a 5020 Blower fan.

You can also find a file to replace the Hotend fan by a 5020 blower. I also made a box for a PCB to regulate the PWM signal noise but it it is compatible with a custom PCB I made (inspired by a video on Youtube) so the file for the box is not shared.

Print Settings

Printer Brand:

Creality

Printer: Ender-3 S1 Plus

Rafts:

No

Supports: No

Resolution:

0,2

Infill: 30%

Filament: Flashforge ASA Black

Notes:

The best print orientation is pictured

For the assembly you will need: 2 x M3 x 14mm screw for the parts coling

3 x M3 8 mm fort the hotend cooling

4x M3 x 4mm inserts for 5020 fan (2 per fan)

4x M3x 25mm screws for 5020 fan (2 per fan)

Category: 3D Printer Parts
