Tealight Molds & Wick Holder

Tealight Mold

- A simple tealight mold that casts x25 tealights. - A soft mold to help keep shape while curing. - The tealights are approximately 38 mm (1.5 in) in diameter by 16 mm (0.63 in) high. - Print the mold in TPU rubber. - Printed on an Ender 3 at .2mm layer height with brim enabled. - How to use: - Place mold flat on a piece of parchment paper. A little bit of tape can be used to hold the mold in place but it is not necessary. - Insert your wicks into the center of each mold. You can use a bit of tape, a double sided sticker, or some melted wax to hold it in place. - Use a wick holder to keep wick centered. - Pour melted wax into each container right up to the brim. - Let the wax harden and cool. - Lift the mold up and remove the parchment paper from underneath. - Push candles out of from the bottom using your thumbs. - Voila! You have made you own tealights.

Tealight Mold BIG

- One solid piece tealight mold that casts x25 tealights. - I recommend using the first version as it works better and is easier to remove candles. This was only made at request of a customer. Thought I'd upload it anyway. - Designed to be printed in TPU rubber. - 0.2mm layer height, 2 perimeters, 5% gyroid infill, 4 top/bottom layers, 4mm brim enabled

EDITS:

March 16th

- removed original x16 version and added a x25 candle version in its place. - added a thick one piece design x25 candle mold. March 25th

- added a x9 tealight version for easier printing - modified the molds to have no bottoms because they were tested and candles were difficult to remove. - added a wick holder because it was difficult to keep wicks straight during pouring.
