Description

PetruziaOffice is my biggest 3d printed handwired mechanical keyboard (yet). The goals were to use the most of the usable pin in a pro micro controller but keeping the keyboard printable in a 22x22 cm printer plate.

The clip in the back is optimized for this tipe of promicro (the one with the type C connector): aliexpress

You will need:

x1 Pro Micro

x4 M3 x 6mm screws

x4 M3 threaded inserts

x4 10mm rubber feet

x5 2u plate mount stabs

I used the qmk firmware and this guides ( guide1 , guide2 , guide3 ) to build the keyboard and the firmware
